Tank Polishing Machine XYD-2HH

鑫艺达不锈钢罐体表面抛光机专为φ800–3000mm罐体与压力容器内外壁的高效打磨抛光而设计。采用砂带与砂轮组合工艺，支持哑光、亮光、镜面处理，可实现Ra<0.2μm超低表面粗糙度，满足食品、制药、化工等对接触表面高洁净度要求的行业。整机具备高效率（10–12㎡/小时）、高一致性、支持重载加工（1–20吨），是大型容器抛光的理想选择。

2500MM

Consult

Introduction

Product Overview

Xinyida-designed stainless steel tank polishing equipment is suitable for both internal and external surface treatment of tanks and pressure vessels (φ800mm–3000mm). It delivers high efficiency (10–12㎡/hour) and can achieve matte, bright, or mirror finishes with surface roughness as low as RA <0.2μm, meeting strict industry standards for contact surfaces.

Key Features

✔ Wide Compatibility: Processes tanks from φ300mm to φ3000mm (length up to 5000mm)
✔ Interchangeable Tools: Supports abrasive belts & grinding wheels for versatile polishing
✔ Heavy-Duty Option: Optional 1–20-ton rolling table for large vessels
✔ Superior Finish: Minimal grit lines, RA <0.2μm mirror polish
✔ Semi-Automatic Operation: 2500mm beam stroke for precision control
✔ Premium Components: WANNA motors, Zhongchen/DELTA VFDs, Schneider electrical parts

Technical Specifications

Parameter	Specification
Model	XYD-1 (JY-1)
Motor Power	4kW / 5.5kW (WANNA)
Efficiency	10–12㎡/hour
Tank Size	φ300–3000mm × 5000mm long
Load Capacity	1–20 tons (optional)
Finish Types	Matte / Bright / Mirror
Control System	Semi-automatic
